Multi Station BLDC Motor Winding Machine

Winding-compatible equipment

It can be universally used for the precision winding of the following motor types:Electric bike(hub motor),Industrial fan and wash machine..etc..

This Multi Station BLDC Motor Winding Machine is engineered to boost productivity for medium-to-high volume BLDC motor manufacturing-covering key applications like home appliance motors (inverter air conditioners, smart washing machines) and industrial small-drive motors (mini variable-frequency conveyors, low-power water pumps)-by leveraging multi-station parallel operation. Unlike single-station equipment, its multi-station layout allows simultaneous execution of winding tasks across different stations, cutting production cycles by up to 40% while maintaining the precision required for BLDC motors' multi-pole, high-efficiency design.

As a dedicated multi-station BLDC coil winding equipment, it integrates fully automated functions tailored to BLDC motor needs: automatic winding with consistent tension control (critical for reducing copper loss in BLDC coils), precision wire arrangement to avoid slot overlap (a major cause of BLDC motor overheating), and synchronized pole changing across stations to ensure batch uniformity. Each station is equipped with an independent die head fixing mechanism, enhancing enameled wire entry stability for BLDC motor stators of varying sizes (from Φ50mm to Φ160mm), while fixtures made from imported materials undergo special heat treatment to resist wear during continuous high-volume operation.

The machine's high-speed control system coordinates all stations seamlessly, allowing operators to assign different BLDC motor models to separate stations (e.g., an 8-pole air conditioner motor to Station 1 and a 12-pole water pump motor to Station 2) without cross-interference. Safety gratings and photoelectric door switches protect operators around the multi-station setup, aligning with industrial safety standards. For manufacturers focusing on efficient, consistent BLDC motor mass production, this Multi Station BLDC Motor Winding Machine balances speed, flexibility, and precision seamlessly.
